The Array class is a template array used to conveniently manipulate data stored in a BufferObject. More...
#include <Array.hpp>
Public Types | |
| typedef T_Scalar | scalar_type |
| typedef T_VectorType | vector_type |
Public Member Functions | |
| virtual size_t | glSize () const |
| Returns the number of scalar components for the array, ie 3 for ArrayFloat3, 1 for ArrayUInt1 etc. | |
| virtual GLenum | glType () const |
| Returns the OpenGL type for the array, ie GL_FLOAT for ArrayFloat3, GL_UNSIGNED_INT for ArrayUInt1 etc. | |
| virtual size_t | bytesPerVector () const |
| void | clear () |
| void | resize (size_t dim) |
| size_t | size () const |
| Returns the number of elements of an array. | |
| size_t | sizeBufferObject () const |
| size_t | scalarCount () const |
| size_t | scalarCountBufferObject () const |
| const T_VectorType * | begin () const |
| T_VectorType * | begin () |
| const T_VectorType * | end () const |
| T_VectorType * | end () |
| T_VectorType & | at (size_t i) |
| const T_VectorType & | at (size_t i) const |
| T_VectorType & | operator[] (size_t i) |
| const T_VectorType & | operator[] (size_t i) const |
| virtual ref< ArrayAbstract > | createArray () const |
| virtual ref< ArrayAbstract > | clone () const |
| Sphere | computeBoundingSphere () const |
| Computes the bounding sphere enclosing the vectors contained in the buffer. | |
| AABB | computeBoundingBox () const |
| Computes the axis aligned bounding box enclosing the vectors contained in the buffer. | |
| void | transform (const mat4 &m) |
| Transforms the vectors contained in the buffer. | |
| void | normalize () |
| Normalizes the vectors contained in the buffer. | |
| vec4 | getAsVec4 (size_t vector_index) const |
Returns a vector from the buffer as a vec4 value. | |
| vec3 | getAsVec3 (size_t vector_index) const |
Returns a vector from the buffer as a vec3 value. | |
| vec2 | getAsVec2 (size_t vector_index) const |
Returns a vector from the buffer as a vec2 value. | |
| int | compare (int a, int b) const |
| Compares two vectors. | |
| void | initFrom (const std::vector< T_VectorType > &vector) |
Static Public Attributes | |
| static const size_t | gl_size = T_GL_Size |
| static const GLenum | gl_type = T_GL_Type |
Detailed Description
template<typename T_VectorType, typename T_Scalar, size_t T_GL_Size, GLenum T_GL_Type>
class vl::Array< T_VectorType, T_Scalar, T_GL_Size, T_GL_Type >
The Array class is a template array used to conveniently manipulate data stored in a BufferObject.
- See also:
- ArrayAbstract
- vl::ArrayFloat1, vl::ArrayFloat2, vl::ArrayFloat3, vl::ArrayFloat4
- vl::ArrayDouble1, vl::ArrayDouble2, vl::ArrayDouble3, vl::ArrayDouble4
- vl::ArrayInt1, vl::ArrayInt2, vl::ArrayInt3, vl::ArrayInt4
- vl::ArrayUInt1, vl::ArrayUInt2, vl::ArrayUInt3, vl::ArrayUInt4
- vl::ArrayByte1, vl::ArrayByte2, vl::ArrayByte3, vl::ArrayByte4
- vl::ArrayUByte1, vl::ArrayUByte2, vl::ArrayUByte3, vl::ArrayUByte4
- vl::ArrayShort1, vl::ArrayShort2, vl::ArrayShort3, vl::ArrayShort4
- vl::ArrayUShort1, vl::ArrayUShort2, vl::ArrayUShort3, vl::ArrayUShort4
- vl::ArrayHFloat1, vl::ArrayHFloat2, vl::ArrayHFloat3, vl::ArrayHFloat4
- vl::ArrayFixed1, vl::ArrayFixed2, vl::ArrayFixed3, vl::ArrayFixed4
- vl::ArrayInt_2_10_10_10_REV1, ArrayInt_2_10_10_10_REV2, ArrayInt_2_10_10_10_REV3, ArrayInt_2_10_10_10_REV4
- vl::ArrayUInt_2_10_10_10_REV1, ArrayUInt_2_10_10_10_REV2, ArrayUInt_2_10_10_10_REV3, ArrayUInt_2_10_10_10_REV4
Definition at line 185 of file Array.hpp.
Member Typedef Documentation
| typedef T_Scalar vl::Array< T_VectorType, T_Scalar, T_GL_Size, T_GL_Type >::scalar_type |
| typedef T_VectorType vl::Array< T_VectorType, T_Scalar, T_GL_Size, T_GL_Type >::vector_type |
Member Function Documentation
| virtual size_t vl::Array< T_VectorType, T_Scalar, T_GL_Size, T_GL_Type >::glSize | ( | ) | const [inline, virtual] |
Returns the number of scalar components for the array, ie 3 for ArrayFloat3, 1 for ArrayUInt1 etc.
Implements vl::ArrayAbstract.
| virtual GLenum vl::Array< T_VectorType, T_Scalar, T_GL_Size, T_GL_Type >::glType | ( | ) | const [inline, virtual] |
Returns the OpenGL type for the array, ie GL_FLOAT for ArrayFloat3, GL_UNSIGNED_INT for ArrayUInt1 etc.
Implements vl::ArrayAbstract.
| virtual size_t vl::Array< T_VectorType, T_Scalar, T_GL_Size, T_GL_Type >::bytesPerVector | ( | ) | const [inline, virtual] |
Definition at line 199 of file Array.hpp.
Referenced by vl::Array< bvec2, GLbyte, 2, GL_BYTE >::resize(), vl::Array< bvec2, GLbyte, 2, GL_BYTE >::size(), and vl::Array< bvec2, GLbyte, 2, GL_BYTE >::sizeBufferObject().
| void vl::Array< T_VectorType, T_Scalar, T_GL_Size, T_GL_Type >::clear | ( | ) | [inline] |
Reimplemented from vl::ArrayAbstract.
| void vl::Array< T_VectorType, T_Scalar, T_GL_Size, T_GL_Type >::resize | ( | size_t | dim ) | [inline] |
Definition at line 205 of file Array.hpp.
Referenced by vl::Array< bvec2, GLbyte, 2, GL_BYTE >::clear(), vl::Geometry::fixTriangleWinding(), vl::Array< bvec2, GLbyte, 2, GL_BYTE >::initFrom(), vl::loadMD2(), and vl::Geometry::mergeDrawCallsWithTriangles().
| size_t vl::Array< T_VectorType, T_Scalar, T_GL_Size, T_GL_Type >::size | ( | ) | const [inline, virtual] |
Returns the number of elements of an array.
Implements vl::ArrayAbstract.
Definition at line 207 of file Array.hpp.
Referenced by vl::Array< bvec2, GLbyte, 2, GL_BYTE >::at(), vl::Array< bvec2, GLbyte, 2, GL_BYTE >::clone(), vl::Array< bvec2, GLbyte, 2, GL_BYTE >::computeBoundingBox(), vl::Array< bvec2, GLbyte, 2, GL_BYTE >::computeBoundingSphere(), vl::Array< bvec2, GLbyte, 2, GL_BYTE >::end(), vl::Geometry::fixTriangleWinding(), vl::Geometry::flipNormals(), vl::loadMD2(), vl::Geometry::mergeDrawCallsWithTriangles(), vl::Array< bvec2, GLbyte, 2, GL_BYTE >::normalize(), vl::Array< bvec2, GLbyte, 2, GL_BYTE >::scalarCount(), vl::Geometry::sortVertices(), and vl::Array< bvec2, GLbyte, 2, GL_BYTE >::transform().
| size_t vl::Array< T_VectorType, T_Scalar, T_GL_Size, T_GL_Type >::sizeBufferObject | ( | ) | const [inline] |
Definition at line 209 of file Array.hpp.
Referenced by vl::Array< bvec2, GLbyte, 2, GL_BYTE >::scalarCountBufferObject().
| size_t vl::Array< T_VectorType, T_Scalar, T_GL_Size, T_GL_Type >::scalarCount | ( | ) | const [inline] |
| size_t vl::Array< T_VectorType, T_Scalar, T_GL_Size, T_GL_Type >::scalarCountBufferObject | ( | ) | const [inline] |
| const T_VectorType* vl::Array< T_VectorType, T_Scalar, T_GL_Size, T_GL_Type >::begin | ( | ) | const [inline] |
| T_VectorType* vl::Array< T_VectorType, T_Scalar, T_GL_Size, T_GL_Type >::begin | ( | ) | [inline] |
| const T_VectorType* vl::Array< T_VectorType, T_Scalar, T_GL_Size, T_GL_Type >::end | ( | ) | const [inline] |
| T_VectorType* vl::Array< T_VectorType, T_Scalar, T_GL_Size, T_GL_Type >::end | ( | ) | [inline] |
| T_VectorType& vl::Array< T_VectorType, T_Scalar, T_GL_Size, T_GL_Type >::at | ( | size_t | i ) | [inline] |
Definition at line 227 of file Array.hpp.
Referenced by vl::Array< bvec2, GLbyte, 2, GL_BYTE >::compare(), vl::Array< bvec2, GLbyte, 2, GL_BYTE >::computeBoundingBox(), vl::Array< bvec2, GLbyte, 2, GL_BYTE >::computeBoundingSphere(), vl::Geometry::flipNormals(), vl::Array< bvec2, GLbyte, 2, GL_BYTE >::getAsVec2(), vl::Array< bvec2, GLbyte, 2, GL_BYTE >::getAsVec3(), vl::Array< bvec2, GLbyte, 2, GL_BYTE >::getAsVec4(), vl::loadMD2(), vl::Array< bvec2, GLbyte, 2, GL_BYTE >::normalize(), vl::Array< bvec2, GLbyte, 2, GL_BYTE >::operator[](), vl::Geometry::sortVertices(), and vl::Array< bvec2, GLbyte, 2, GL_BYTE >::transform().
| const T_VectorType& vl::Array< T_VectorType, T_Scalar, T_GL_Size, T_GL_Type >::at | ( | size_t | i ) | const [inline] |
| T_VectorType& vl::Array< T_VectorType, T_Scalar, T_GL_Size, T_GL_Type >::operator[] | ( | size_t | i ) | [inline] |
| const T_VectorType& vl::Array< T_VectorType, T_Scalar, T_GL_Size, T_GL_Type >::operator[] | ( | size_t | i ) | const [inline] |
| virtual ref<ArrayAbstract> vl::Array< T_VectorType, T_Scalar, T_GL_Size, T_GL_Type >::createArray | ( | ) | const [inline, virtual] |
Definition at line 237 of file Array.hpp.
Referenced by vl::Array< bvec2, GLbyte, 2, GL_BYTE >::clone().
| virtual ref<ArrayAbstract> vl::Array< T_VectorType, T_Scalar, T_GL_Size, T_GL_Type >::clone | ( | ) | const [inline, virtual] |
Implements vl::ArrayAbstract.
| Sphere vl::Array< T_VectorType, T_Scalar, T_GL_Size, T_GL_Type >::computeBoundingSphere | ( | ) | const [inline, virtual] |
Computes the bounding sphere enclosing the vectors contained in the buffer.
Implements vl::ArrayAbstract.
| AABB vl::Array< T_VectorType, T_Scalar, T_GL_Size, T_GL_Type >::computeBoundingBox | ( | ) | const [inline, virtual] |
Computes the axis aligned bounding box enclosing the vectors contained in the buffer.
Implements vl::ArrayAbstract.
| void vl::Array< T_VectorType, T_Scalar, T_GL_Size, T_GL_Type >::transform | ( | const mat4 & | m ) | [inline, virtual] |
Transforms the vectors contained in the buffer.
Implements vl::ArrayAbstract.
| void vl::Array< T_VectorType, T_Scalar, T_GL_Size, T_GL_Type >::normalize | ( | ) | [inline, virtual] |
Normalizes the vectors contained in the buffer.
Implements vl::ArrayAbstract.
| vec4 vl::Array< T_VectorType, T_Scalar, T_GL_Size, T_GL_Type >::getAsVec4 | ( | size_t | vector_index ) | const [inline, virtual] |
Returns a vector from the buffer as a vec4 value.
Implements vl::ArrayAbstract.
| vec3 vl::Array< T_VectorType, T_Scalar, T_GL_Size, T_GL_Type >::getAsVec3 | ( | size_t | vector_index ) | const [inline, virtual] |
Returns a vector from the buffer as a vec3 value.
Implements vl::ArrayAbstract.
| vec2 vl::Array< T_VectorType, T_Scalar, T_GL_Size, T_GL_Type >::getAsVec2 | ( | size_t | vector_index ) | const [inline, virtual] |
Returns a vector from the buffer as a vec2 value.
Implements vl::ArrayAbstract.
| int vl::Array< T_VectorType, T_Scalar, T_GL_Size, T_GL_Type >::compare | ( | int | a, |
| int | b | ||
| ) | const [inline, virtual] |
| void vl::Array< T_VectorType, T_Scalar, T_GL_Size, T_GL_Type >::initFrom | ( | const std::vector< T_VectorType > & | vector ) | [inline] |
Member Data Documentation
The documentation for this class was generated from the following file:
- /home/master/UCL/VisualizationLibrary/src/vlGraphics/Array.hpp
